Premium Quality Clicky Feeling
| Feeling | Clicky | |
| Rating | DC12V10mA | |
| Cotact resistance | 100mΩMax | |
| Insulation resistance | 100MΩMinDC500V | |
| withstanding voltage | AC100V(50-60HZ)for1Minute | |
| Tactile force | 55±10gf | |
| Actuation force | 45±10gf | |
| Actuation travel | 1.8±0.3mm | |
| Total travel | 3.60/-0.3mm | |
| Electrical life | 80,000,000Cycles | |
| Operating temperature | -20℃- 70℃ | |
| Weather resistance | ||
| low temperature resistance | -20℃±2℃ | 48H |
| heat resisting property | 70℃±2℃ | 48H |
| Moisture resistance | 60℃±2℃90~95%RH | 48H |
